PEN-HF
Enables swift and efficient printing while ensuring safety and reliability, perfect for dental 3D printing and food-contact tools
-
High printing speed: Printing speed up to 300 mm/s with exceptional printing accuracy
-
Superior Printability: Excellent bed adhesion, minimal warping, and extremely fast print speeds at 265-275°C.
-
Accessible: High-performance benefits without needing ultra-premium 3D printers.
-
Precision Manufacturing: Available in 1.75mm and 2.85mm diameters with strict tolerances.
-
Exceptional chemical resistance, transparency and UV-blocking
Color:
Nearly Transparent
Diameter (mm):
1.75 ± 0.03 & 2.85 ± 0.06
Net filament weight (g):
200 & 1000
Color:
Nearly Transparent
Biocompatible, Eco-conscious 3D Printing Filament
-
Compliance with
FDA 21 CFR 177.1637, ensure consumer health and safety
-
Low Extractable potential and PFAS-free
-
Complies with ADCF, REACH, and RoHS 2
-
Autoclave / Gamma / E‑beam sterilizable
Printing Orientation:
The FDM process creates parts with a layered structure, causing mechanical properties to be anisotropic based on print orientation.*1
-
Flat XY orientation: predominant mechanical strength from infill
-
Side YZ orientation: predominant mechanical strength from walls
-
Upright Z orientation: interlayer adhesion strength.
#: third party testing by:
*1 The values reported in TDS represent the average from a batch of 10 test specimens. For tensile, flexural, and impact properties of the 3D printed test specimens were produced using a 0.4 mm nozzle, 100% infill, print speed of 60mm/s, a nozzle temperature of 270°C and a build plate temperature of 80°C. FLXR Engineering is continuously working on expanding the TDS data
Recommended Printing Profile:
Real printing speed
CHEMICAL RESISTANCE TABLE
*2
*2 The chemical resistance of PEN is evaluated by the following test method:
Specimens are immersed in the chemical (liquid) at 23°C for 30 days.
Ranking definition: A: weight change <1%, tensile strength retained >95%; B: weight change between 1~10%, tensile strength retained >75%;
C: weight change >10%, tensile strength retained <75%; D: swelled or dissolved within 120 hours.
Market Positioning Matrix of Food-grade Materials
Comparison Table for Food-grade Materials on the Market
Comparison of Mechanical Strength for Food-grade Materials
Comparison of Temperature Resistance for Food-grade Materials
